ISO/IEC 15693

NXP ICODE® NFC Tag

NXP ICODE® NFC Tag

NXP ICODE® SLIX

RFID vicinity type tags based on ISO/IEC 15693 and ISO/IEC 18000-3 specifications.

ISO/IEC 15693, is an ISO standard defined by the International Organization of Standardization for RFID card or contactless vicinity objects with greater distance as compared with other High-Frequency RFID cards.

The reading distance for the ICODE SLIX tag can be operated up to a distance of 1.5 meters without a battery.

ICODE® SLIX tag complies with the NFC Forum Tag Type 5 standard. Easily to engage your target customer via IoT device.

RF interface

  • ISO/IEC 15693
  • NFC Forum Tag Type 5
  • Operating frequency: 13.56 MHz
  • Operating distance: up to 1.5 m
  • Up to 53 kbit/s data transfer rate
  • Data integrity: 16-bit CRC
  • Electronic Article Surveillance (EAS)
  • True anti-collision

Security

  • UID: 64 bits
  • 32-bit password-protected for EAS and AFI
  • 32-bit password-protected for Label Destroy & Privacy Mode (not available for SLIX）

User Memory

  • SLIX: 896 bits
  • SLIX-2: 2528 bits
  • SLIX-L: 256 bits
  • SLIX-S: 1280 bits

Applications

  • Retail Smart Packaging
  • Library management
  • Supply chain management
  • Brand protection
  • Anti-counterfeiting

NFC Label

Click to check the available NFC Label Dimensions for ICODE® SLIX

NXP ICODE® ILT

RFID vicinity type tags based on ISO/IEC 15693 and ISO/IEC 18000-3 specifications.

The reading distance for the ICODE ILT tag can be operated up to a distance of 1.5 meters without a battery.

ICODE® ILT IC is designed for Item Level Targeting, which is easy to integrate into the global identification system EPC.

RF interface

  • ISO/IEC 15693
  • Operating frequency: 13.56 MHz
  • Operating distance: up to 1.5 m
  • Electronic Article Surveillance (EAS)
  • True anti-collision up to 800 tags/s

Applications

  • Retail & Supply chain management
  • Toys and Board Games

Features

  • Up to 240-bit of EPC memory
  • 96-bit tag identifier (TID) including 48-bit unique serial number
  • 512-bit user memory for ILT-M
  • ICODE® ILT tag can be used as EAS tag without backend database
  • Input capacitance: 23.5 pF / 97 pF

NFC Label

Click to check the available NFC Label Dimensions for ICODE® ILT
